Input Frequency Range 10.7 ~ 12.75 GHz

Output Frequency Range:
Vertical: 290 ~ 2340 MHz
Horizontal: 290 ~ 2340 MHz

LO Frequency 10.41 GHz
Noise Figure 0.1 dB (Typ.)
Image Rejection 40 dB (Min.)
Current Consumption 0.85W (max.) (70mA @ +12V DC)
Power voltage 9 - 19V DC
Output Connector Type 75 OHMS female F-connector
Output Spurious <-60dBm
Operating Temperature Range -40°C ~ +60°C
Feed Lenght 40 mm
